See all High Purity Alumina families

SA – 4N α alumina milled powder range

SA products are jet milled (-CR) & ball milled (-DBM) powders for technical ceramic and bioceramic applications

Ask for information

Products characteristics

Standard products
(Typical values)
SA5CR SA8 DBM SA80*
Crystalline phase 100% α 100% α Transition
Specific Surface Area (m²/g) BET 5 8 80
PSD d50 (µm)
Laser diffraction
Horiba LA950
1.4 0.33 20.6
Green Density (g/cm³)
(Uniaxial pressing at 350 bar)
1.74 2.22
Fired Density (g/cm³)
(Sintered at 1510°C for 2 hours)
3.44 3.94
Shrinkage (%) 17.4

* SA80 is an agglomerated powder, otherwise the SA products are jet milled (-CR) & ball milled (-DBM) powders.
Contact us so that we provide assistance in making your SA product choice.

Do not hesistate to download our Baikalox® leaflet hereunder to help you find the High Purity Alumina solutions that meet your needs.

Resources

  • SA-DBM Technical Data Sheet
  • SA5 Technical Data Sheet
  • SA80 Technical Data Sheet
  • Baikalox®_Leaflet_Baikowski®
  • High-Purity-Alumina_safety-data-sheet_Baikowski

Main applications

Electronic ceramics

Electronic ceramics

CMC

CMC

Bioceramics

Bioceramics

Filtration

Filtration
